Securitron PB2E Push Button, Momentary, Single Gang, Includes Switchable Green, Red and Blue ADA Lenses,

Product Overview The model PB2E is a spring loaded momentary 2″ square, exit button, mounted on a stainless steel single gang outlet box cover. The SPDT contacts switch when the button is depressed and return when it is released. The contacts are UL listed with 5 AMP capacity. The PB2E can be used for momentary release of fail safe or fail secure electric locks. If interfaced with a release hold timer, it can provide for timed release of electric locks. It may also be used to input a REX (request to exit) signal to a card reader system. We recommend that the local building or fire safety authority be consulted prior to using exit buttons for door egress. They may require a “no special knowledge” exit device such as Securitron’s Touch Sense Bar. Main Features SPDT 10 A contacts (DPDT available, see How to Order section) Large 2″ diagonal flush button Momentary operation 12/24 VDC LED button illumintaion and a red LED (illuminated version only) Stainless steel single gang plate (back box included on illuminated versions) Show More Show Less
