Securitron EEB2 Emergency Exit Button with 30 Second Release, Single Gang, Interchangeable Green, Red, and Handicap

Product Overview   2″ Square Emergency Exit Button with 30 second push button release. The device is mounted on a stainless steel, single-gang faceplate and features internal double-break wiring. The button is field selectable at 12 or 24VDC to match the voltage of the triggered lock. The EEB2 can be used as a backup access control device in the event of an exit sensor failure. The red and white wires from the EEB2/3N must receive voltage from the same power supply. Weather Option:WCC and WBB available for all Single Gang Push Buttons, Keyswitches and Keypads. Safety Notice:Securitron’s UL294 certification indicates that when the EEB is used with the XMS Motion Sensor, it meets the NFPA Life Safety Code 101 requirements for exit of access-controlled egress doors.   Main Features Retriggerable For indoor use only Mounted next to door Single Gang or Narrow Stile SPDT 3 Amp wet N/C contacts EEB3N includes switchable green and red lenses EEB2 includes switchable green, red and blue ADA lenses Momentarily pressing the button releases door for 30 seconds Operates on 12 or 24 VDC (must be same voltage as the installed lock) Emergency Exit Buttons offer additional safety, as required by code, for possible malfunction of motion exit sensor Show More Show Less
