BAYKAL HNC 4110 hydraulic guillotine shears

BAYKAL HNC 4110 hydraulic guillotine shears built in 2019 in Turkey are designed for precision cutting of workpieces with a maximum thickness of 10 mm. The machining process is performed by extremely precise cutting knives with adjustable gap between blades. The all-steel construction combined with a powerful hydraulic system additionally ensure the highest stability and machining performance. The BAYKAL HNC 4110 guillotine shears have been in use for a small amount of time – so far they have worked only 560 hours. The total weight of the machine is 15400 kg. Technical specifications of the BAYKAL HNC 4110 guillotine shears HMI panel: SIEMENS SIMATIC HMI maximum sheet metal length: 4060 mm maximum sheet metal thickness (Rm<450N/mm2): 10 mm maximum sheet metal thickness (Rm<700 N/mm2): 6 mm stroke rate: 10-16/min maximum back stop distance: 1000 mm operating hours: 560 h working pressure: 260 bar motor power: 23.55 kW power supply: 3x 400 V; 50 Hz dimensions (L x W x H): 4900 x 2970 x 2370 mm weight of machine: 15400 kg
